API SwivelCheck

Swivel Axis Calibration for Rotary Tables.

What is the SwivelCheck?

Excellent stand-alone system for measuring swivel axes and rotational axes in horizontal and vertical position.



Who is this for?

SwivelCheck is essential in industries like aerospace, automotive, and manufacturing where precision is critical for dynamic swivel axis calibration, machine tool verification, and automation control.



SwivelCheck for Swivel Axis Calibration

SwivelCheck Features

Off Axis

Mounting

800º

ANGULAR RANGE

±1 ARCSEC

PITCH & YAW ACCURACY

4.9 kg

in Weight

Key Industries

The SwivelCheck is primarily used in industries that have Rotary Table CNC’s and rely on precision machining and manufacturing.

Key industries include aerospace, automotive, defense, energy, and any sector that utilizes CNC machines and requires accurate calibration of rotational axes. The SwivelCheck ensures the precision and reliability of machinery, contributing to the quality and consistency of manufactured components.

Swivel Axis Calibration - SwivelCheck

Swivel Axis Calibration Applications

Offering a versatile and precise calibration solution, the SwivelCheck is designed for measuring and calibrating swivel and rotational axes in various industrial applications.

API’s extensive experience across aerospace, automotive, energy, heavy machinery, agricultural equipment, military & defense, and machine tools sectors ensures SwivelCheck meets diverse industry needs.

SwivelCheck excels in tasks such as dynamic axis calibration, machine tool verification, and automation control, providing accuracy and reliability essential for quality manufacturing processes.



Applications include:

  • Dynamic Axis Calibration
  • Machine Tool Verification
  • Automation Control

Technical Specifications

Range
Minimum Test Increment:
Accuracy
Stand-Alone Mode (Swivelcheck Only)
Dual Mode (XD Laser/Swivelcheck)
Mounting
Shank, Flange, or Base Mounting
Shank Diameter
Sensor Weight
Controller Weight
Sensor Size
Controller Size
Range of Measurements
800º(± 400º)
0.0002º
±2 arcsecond
±1 arcsecond
Yes
25mm
3.2kg (7.0 lbs)
1.7kg (3.7 lbs)
165mm x 115mm x 150mm (6.5 in x 4.5 in x 6.0 in)
160mm x 160mm x 100mm (6.25 in x 6.25 in x 4.0 in)
